Commercial charging Management
Remote control your charging station with OCPP Protocol.
Monitoring and Reporting
Track and adjust power consumption.
Economic
Select your energy tariff and let the system automatically work out the cheapest time to charge your EV.
Advantages
More Durable
PV VO special high pc material can bear smashing, throwing and other cruel environment.
OCPP full function
Our charging pile has ocpp1.6-J full functions, including core functions.
Smart charging , appointment, remote
Firmware upgrade, etc.
Modular design
Configurations can be added or subtracted according to your request, which is also simple and convenient to assemble and maintain to save your operating cost.
More secure
The charger uses MID certified meter to ensure
Accuracy and built-in RCD to secure safety.
The charger also can includes type B RCD to make the charging safer.
Parameter
Specification | AE220007BY01 | AE40011BY01 | AE400022BY01 | |
Voltage | 230VAC±10% | 380VAC±10% | 380VAC±10% | |
Output Current | 32A | 16A | 32A | |
Frequency | 50/60Hz | 50/60Hz | 50/60Hz | |
Output Power | 7Kw | 11Kw | 22Kw | |
Emergency Stop Button | Yes | |||
Display | LCD touch Screen | |||
RFID Function | 5pcs cards | |||
Residual current protection | Type B/Type A 30mA+DC6mA(option) | |||
Energy Meter | MID Certificated | |||
Charging outlet | One charging socket(Type2)/4 M charging cable | |||
Housing Material | PCV 0 for outdoor | |||
Front Ponel | PC | |||
Installation Method | Wall-mount/Floor-stand | |||
Network Gateway | Ethernet/Wifi/4G | |||
Communication Protocol | OCPP1.6(J-Son) | |||
Safety Standard | En 61851-1 | |||
Warranty | 2 years | |||
Protection Level | IP67 | |||
Temperature/Humidity | -30℃-50℃/5%-95% without condensation | |||
Working Altitude | <2000M | |||
Application Site | Indoor/outdoor | |||
Product Size | 398X324X20mm | |||
Product Weight | 10KG | 11KG | 12KG |
