EV Wallbox Home Charger AC 3.5KW for EV Charging

PRODUCTS > AC Charger > EV Wallbox Home Charger AC 3.5KW for EV Charging

EV Wallbox Home Charger AC 3.5KW for EV Charging

Features

• Simple charge

Plug and easy to play very convenient for home use
Real-time Display
Voltage current, time, status, fault and power. Take a look will know all!
Highly Integrated
Highly integrated and compact design make

• Maintenance and shipment easier

More safety
The charger include over-current, over-voltage, surge, low voltage, leakage protection and DC protection.

Features



  • Simple charge



       Plug and easy to play very convenient for home use

       Real-time Display

       Voltage current, time, status, fault and power. Take a look will know all!

       Highly Integrated

       Highly integrated and compact design make



  • Maintenance and shipment easier



       More safety

      The charger include over-current, over-voltage, surge, low voltage, leakage protection and DC protection.

Advantages



  • LCD screen



       4.3”super screen, can check the screen information easily.



  • Switch design



       Plug in, then the switch can start or stop charging



  • Metal enclosure



        Super heat absorption performance, alleviate overheating during charging. Increase service life.



  • Integrated appearance & structural design



       EV charging station with socket or plug is optional according to your request.

Parameter

Specification

AE220035BY01

AE40011BY01

AE400022BY01

Voltage

230VAC±10%

380VAC±10%

380VAC±10%

Output Current

16A

16A

32A

Frequency

50/60Hz

50/60Hz

50/60Hz

Output Power

3.5Kw

11Kw

22Kw

Emergency Stop Button

Yes

Display

LCD Screen

RFID Function

3pcs cards

Residual current protection

Type A 30mA+DC6mA

Charging outlet

One charging socket(Type2)/4.5M charging cable

Housing Material

PCV 0 for outdoor

Front Ponel

PC

Installation Method

Wall-mount/Floor-stand

Safety standard

En 61851-1

Warranty

2 years

Protection Level

IP67

Temperature/Humidity

-30℃-50℃/5%-95% without condensation

Working Altitude

2000M

Application Site

Indoor/outdoor

Product Size

398X324X20mm

Product Weight

5.3/7.0KG

5.2/8.2KG

5.5/8.5KG

Optional Parts

Residual current protection

Type B RCD

Energy Meter

MID certificated
